当前所在位置：首页>产品中心>气动工具>气动扳手>气动角向螺帽扳手LTV28/38/48

气动角向螺帽扳手LTV28/38/48

所属品牌：阿特拉斯·科普柯Atlas Copco

产品型号：LTV28/38/48

ATLAS阿特拉斯LTV28/38/48角向螺帽扳手，具有高速度以及精准度高的优点，可以实现准确快速的拧紧工作，同时这款ATLAS螺帽扳手采用了人体工程学设计，轻巧耐用以及极低的反作用力，易上手可以获得不错的生产效益。

点我询价

商品描述
商品询价热度

阿特拉斯ATLAS扳手LTV28/38/48

在狭窄空间中有良好的可达性

可靠性高

持续高精度

高扭矩精度

强大的马达

螺旋切角齿轮

由于重量轻，舒适操作

专为高速和小尺寸而设计

容易扭转

ATLAS气动角向螺帽扳手LTV各型号参数

型号	ID订货号	螺栓尺寸	方头驱动器	扭矩范围软接头值>	扭矩范围软接头值<	空载速度	重量	长度	角头高度	角中心到一边	空转速度下的空气消耗量	推荐的软管尺寸	进气口螺纹	声压	声音标准	声音不确定度	震动标准	震动值	经过 EAC 认证	EC 标准	工作压力<	型号类型	断气式	EU 指令	Ford 认证	可反转	声功率	ATEX	ATEX 代码	Front part interface	套筒尺寸
LTV38 R42-10	8431060355	M8 mm	3/8 inch	15 ft lb	31 ft lb	400 r/min	4.4 lb	436 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N10/11 TR	Yes	93 dB(A)
LTV38 N68-13	8431060248	M10 mm	1/2 inch	22 ft lb	40 ft lb	370 r/min	4.4 lb	427 mm	41 mm	20 mm	42 cfm	10 mm	1/4 inch	78 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		No
LTV38 R42-13	8431060369	M8 mm	1/2 inch	15 ft lb	31 ft lb	400 r/min	4.8 lb	453 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N11 TR	Yes	93 dB(A)
LTV28 R12-10	8431060163	M6 mm	3/8 inch	4 ft lb	9 ft lb	800 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV48 R200-L13	8431053498	M14 mm	1/2 inch	85 ft lb	148 ft lb	100 r/min	8.3 lb	610 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes	95 dB(A)
LTV48 R200-85-ATEX	8431053491	M14 mm	1/2 inch	85 ft lb	150 ft lb	80 r/min	8.3 lb	610 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 dB(A)	ISO15744	3 dB(A)	ISO28927-2	>2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	95 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV38 R85-170-ATEX	8431060343	M10-12 mm	1/2 inch	29 ft lb	61 ft lb	150 r/min	6.1 lb	530 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	93 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV38 R57-13	8431060351	M10 mm	1/2 inch	22 ft lb	41 ft lb	280 r/min	4.8 lb	453 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N12 TR	Yes	93 dB(A)
LTV28 R28F-RR	8431060197	M8 mm	3/8 inch	10 ft lb	21 ft lb	340 r/min	4.0 lb	300 mm	150 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N9 TR	Yes
LTV38 N55-10	8431060214	M10 mm	3/8 inch	22 ft lb	40 ft lb	440 r/min	4.0 lb	410 mm	34.5 mm	18 mm	42 cfm	10 mm	1/4 inch	78 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		No
LTV28 N28-10	8431060084	M8 mm	3/8 inch	10 ft lb	21 ft lb	500 r/min	2.9 lb	325 mm	29.5 mm	13.5 mm	23 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		No
LTV28 R15-10	8431060155	M6 mm	3/8 inch	5 ft lb	11 ft lb	560 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV38 R50-ATEX	8431060348	M10 mm	3/8 inch	18 ft lb	36 ft lb	330 r/min	4.4 lb	436 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	93 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV38 R50 HAD	8431060382	M10 mm		18 ft lb	36 ft lb	360 r/min	4.8 lb	453 mm	41 mm	20 mm	16 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N11 TR	Yes	93 dB(A)			50 HAD
LTV38 R160-ATEX	8431060373	M12 mm	1/2 inch	40 ft lb	118 ft lb	100 r/min	7.2 lb	500 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	93 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV38 R70-13	8431060346	M10 mm	1/2 inch	24 ft lb	50 ft lb	225 r/min	5.3 lb	487 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N12/13 TR	Yes	93 dB(A)
LTV38 R50-13	8431060371	M10 mm	1/2 inch	18 ft lb	36 ft lb	330 r/min	4.8 lb	453 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes	93 dB(A)
LTV38 R65-ATEX	8431060111	M12 mm	1/2 inch	20 ft lb	48 ft lb	120 r/min	5.7 lb	465 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	93 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV28 R28-120	8431060135	M8 mm	3/8 inch	5 ft lb	21 ft lb	120 r/min	3.1 lb	350 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV48 R120-L13	8431053488	M12 mm	1/2 inch	51 ft lb	88 ft lb	215 r/min	7.6 lb	590 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N14/15 TR	Yes	95 dB(A)
LTV28 N15-10	8431060099	M6 mm	3/8 inch	5 ft lb	11 ft lb	950 r/min	2.6 lb	305 mm	29.5 mm	13.5 mm	23 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		No
LTV48 R150-FS	8431061017	M12 mm		44 ft lb	111 ft lb	180 r/min	7.6 lb	590 mm	70 mm	25 mm	59 cfm	12.7 mm	1/2 inch	84 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes	95 dB(A)			200 FS	19 mm
LTV38 R85-13	8431060338	M10-12 mm	1/2 inch	29 ft lb	61 ft lb	190 r/min	6.1 lb	530 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N14 TR	Yes	93 dB(A)
LTV38 R42 HAD	8431060375	M8 mm		15 ft lb	31 ft lb	430 r/min	4.8 lb	453 mm	41 mm	20 mm	16 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N10/11 TR	Yes	93 dB(A)			50 HAD
LTV38 R85-HAD	8431060958	M10-12 mm		30 ft lb	67 ft lb	210 r/min	6.5 lb	530 mm	52 mm	25 mm	16 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N14 TR	Yes	93 dB(A)			200 HAD
LTV28 R28-42	8431060144	M8 mm	1/4 inch	10 ft lb	21 ft lb	340 r/min	3.1 lb	390 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744		ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV28 R07-6	8431060165	M5 mm	1/4 inch	1.8 ft lb	5 ft lb	1100 r/min	2.9 lb	334 mm	28.5 mm	10 mm	17 cfm	8 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV28 RL28-10	8431060133	M8 mm	3/8 inch	10 ft lb	21 ft lb	80 r/min	3.1 lb	350 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV38 N45-10	8431060206	M8 mm	3/8 inch	16 ft lb	33 ft lb	520 r/min	4.0 lb	410 mm	34.5 mm	18 mm	42 cfm	10 mm	1/4 inch	78 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N11 TR	No
LTV28 R20-10	8431060150	M6 mm	3/8 inch	7 ft lb	15 ft lb	530 r/min	3.1 lb	355 mm	34.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N6/7/8 TR	Yes
LTV28 R28-10	8431060140	M8 mm	3/8 inch	10 ft lb	21 ft lb	340 r/min	3.1 lb	350 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N9 TR	Yes
LTV38 R40-LT-HAD	8431060952	M8-10 mm		11 ft lb	30 ft lb	210 r/min	6.5 lb	530 mm	52 mm	25 mm	16 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes	93 dB(A)			200 HAD
LTV48 R150-L13	8431053493	M12 mm	1/2 inch	51 ft lb	111 ft lb	170 r/min	7.6 lb	590 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes	95 dB(A)
LTV38 R91-ATEX	8431060345	M10-12 mm	1/2 inch	29 ft lb	67 ft lb	140 r/min	6.5 lb	530 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	93 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV28 R07-42	8431060173	M5 mm	1/4 inch	1.8 ft lb	5 ft lb	1100 r/min	2.9 lb	334 mm	28.5 mm	10 mm	17 cfm	8 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV28 R20-42	8431060148	M6 mm	1/4 inch	7 ft lb	15 ft lb	420 r/min	3.1 lb	350 mm	34 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV38 N85-13	8431060252	M10 mm	1/2 inch	29 ft lb	63 ft lb	300 r/min	4.8 lb	460 mm	41 mm	20 mm	42 cfm	10 mm	1/4 inch	78 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		No
LTV38 R70-140-ATEX	8431060356	M10 mm	1/2 inch	20 ft lb	50 ft lb	120 r/min	5.3 lb	500 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	93 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV38 R50-175-ATEX	8431060353	M8 mm	3/8 inch	15 ft lb	36 ft lb	175 r/min	4.8 lb	448 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	EN 13463-1:2009, ISO 11148-6	100 psig	Angle	Yes	2006/42/EC, 2014/34/EU		Yes	93 dB(A)	Yes	EX II 3 GD IIB 135°C (T4)
LTV48 R200-FS	8431061021	M14 mm		85 ft lb	148 ft lb	100 r/min	8.3 lb	610 mm	70 mm	25 mm	59 cfm	12.8 mm	1/2 inch	84 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes	95 dB(A)			200 FS	19 mm
LTV38 N31-10	8431060204	M8 mm	3/8 inch	13 ft lb	23 ft lb	800 r/min	3.7 lb	400 mm	34.5 mm	13.5 mm	42 cfm	10 mm	1/4 inch	78 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N9/10 TR	No
LTV28 N30-10	8431060081	M8 mm	3/8 inch	11 ft lb	22 ft lb	400 r/min	2.9 lb	325 mm	29.5 mm	13.5 mm	23 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		No
LTV28 R07-Q	8431060168	M6 mm	1/4 inch	1.8 ft lb	5 ft lb	1100 r/min	2.9 lb	334 mm	28.5 mm	10 mm	17 cfm	8 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV28 R15-6	8431060152	M6 mm	1/4 inch	5 ft lb	11 ft lb	560 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
LTV38 R50-10	8431060363	M10 mm	3/8 inch	18 ft lb	36 ft lb	330 r/min	4.4 lb	436 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC	CA N11 TR	Yes	93 dB(A)
LTV38 R65-FS	8431060987	M12 mm		25 ft lb	48 ft lb	280 r/min	5.7 lb	515 mm	53 mm	20 mm	38 cfm	10 mm	1/4 inch	82 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes	93 dB(A)				16 mm
LTV28 R15-Q	8431060153	M6 mm	1/4 inch	5 ft lb	11 ft lb	560 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 dB(A)	ISO15744	3 dB(A)	ISO28927-2	<2.5 m/s²	Yes	ISO 11148-6	100 psig	Angle	Yes	2006/42/EC		Yes
